Fluke 8846A Digital Multimeter

Fluke 8846A is a high-precision digital multimeter with 6.5-digit resolution designed for accurate measurements in laboratory and production environments. It can measure voltage, current, and resistance with high precision and offers additional functions for frequency, period, capacitance, and temperature measurements.

Main Specifications:

• Resolution: 6.5 digits
• Basic DC voltage accuracy: up to 0.0024%
• Current measurement range: from 100 μA to 10 A with resolution up to 100 pA
• Resistance measurement range: from 10 Ω to 1 GΩ with resolution up to 10 μΩ
• Dual display: allows simultaneous display of two parameters of the same signal
• Graphical display modes: TrendPlot™, statistics, and histograms
• USB ports: for connecting external storage devices

Additional Features:

• Capacitance and temperature measurement: enables the device to function as a capacitance meter and thermometer
• 2x4 wire resistance measurement function: allows 4-wire measurements using only two leads
• Fluke 45 and Agilent 34401A emulation: ensures compatibility with existing systems

Applications:

Fluke 8846A is suitable for production testing, research and development, as well as service applications requiring high accuracy and measurement reliability.
