Keysight DSOX3054A Oscilloscope

The Keysight DSOX3054A oscilloscope is a high-performance instrument from the InfiniiVision 3000 X-Series, designed for detailed real-time signal analysis. It features four analog channels and a 500 MHz bandwidth.

Main Technical Specifications:

• Bandwidth: 500 MHz
• Number of Channels: 4 analog
• Sampling Rate: Up to 4 GS/s
• Memory Depth: 2M points (expandable to 4M points)
• Waveform Update Rate: Up to 1,000,000 waveforms per second
• Display: 8.5-inch color WVGA



Features:

• High Waveform Update Rate: Provides a high probability of capturing rare or random events with an update rate of up to 1,000,000 waveforms per second.
• Deep Memory: Allows for capturing long signals without reducing the sampling rate, which is especially useful for analyzing complex or slow events.
• Multi-functionality: Integrates 5 instruments in one: an oscilloscope, logic analyzer (optional), function/arbitrary waveform generator (optional), digital voltmeter, and protocol analyzer.
• Upgradability: Allows for future upgrades to bandwidth, additional digital channels, and other features, ensuring investment protection.



Additional Options:

• Function/Arbitrary Waveform Generator (Option DSOX3WAVEGEN): Built-in generator supporting AM, FM, and FSK modulation, as well as the ability to create arbitrary waveforms.
• Digital Channels (Option DSOX3MSO): Expandable up to 16 digital channels for mixed-signal analysis.
• Segmented Memory: Optimizes memory usage when capturing signals with a low duty cycle, such as packet-based serial buses or pulse signals.
