Crown Macro-Tech 5000i Amplifier

Crown Macro-Tech 5000i is a two-channel power amplifier that delivers 2500W per channel at 4 ohms and 5000W in bridge mode at 8 ohms. It features built-in analog signal processing and network connectivity, allowing system operators to monitor and control the amplifier from anywhere.

Key Features

• Patented Class I circuitry provides high power with minimal losses.
• Durable construction designed for long-term use in demanding environments.
• Universal power supply ensures maximum performance in any country.
• Built-in monitoring of load, line voltage, input, and output.
• Standard Ethernet network connection via System Architect for remote monitoring and control.

Technical Specifications

• Frequency Response: ±0.25 dB.
• Signal-to-Noise Ratio: greater than 112 dB.
• Total Harmonic Distortion (THD): less than 0.1%.
• Damping Factor: greater than 5000.
• Input Impedance: 20 kΩ (balanced), 10 kΩ (unbalanced).
• Maximum Input Level: +20 dBu.
• Load Impedance: Stereo: 1/2/4/8/16 Ω; Bridge: 2/4/8 Ω.
• Input Sensitivity: 1.4V RMS, gain 32 dB, gain 26 dB.
• Dimensions: 19" x 3.5" x 16.2" (48.3 cm x 8.9 cm x 41.1 cm).
• Net Weight: 28 lbs (12.7 kg).

Crown Macro-Tech 5000i combines high power, reliability, and advanced technology, making it an excellent choice for professional sound systems.
